Spring Boot Command Pattern Example

The Command Pattern is one of the most versatile and widely used behavioral design patterns. It encapsulates a request as an object, allowing you to parameterize, queue, and execute actions dynamically — all without tightly coupling the caller to the actual logic being executed.

In this article, we’ll explore how to apply the Command Pattern in a real-world Spring Boot project, where we execute different text encoding and decoding algorithms such as Caesar, Atbash, and ROT13.

This example is designed to be both educational and practical — ideal for developers who want to deeply understand the pattern beyond theory.

TL;DR: If you want to skip the explanation and dive straight into the code, check out the full implementation on GitHub: https://github.com/ercansormaz/command-pattern

---

Core Idea of the Command Pattern

The Command Pattern decouples the invoker (the object that triggers an action) from the receiver (the object that performs it).
Each command encapsulates:

• The action to perform
• The receiver of that action
• The parameters needed to perform it

This separation provides flexibility for executing, batching, or even undoing operations without changing the invoker’s logic.

---

How It Works

1. Command Interface

Every command implements a common interface:

public interface CryptoCommand {
  String execute();
}

2. Concrete Commands

Each algorithm has its own command class, e.g.:

@RequiredArgsConstructor
public class CaesarEncodeCryptoCommand implements CryptoCommand {

  private final CaesarCipher chiper;
  private final CryptoCommandInput input;

  @Override
  public String execute() {
    return chiper.encode(input.getInput(), input.getShift());
  }

}

3. Factories

To decouple instantiation, each algorithm has a factory:

@Component
@RequiredArgsConstructor
public class CaesarEncodeCryptoCommandFactory implements CryptoCommandFactory {

  private final CaesarCipher caesarCipher;

  @Override
  public CryptoCommand create(CryptoCommandInput input) {
    return new CaesarEncodeCryptoCommand(caesarCipher, input);
  }

  @Override
  public CryptoMethod getMethod() {
    return CryptoMethod.CAESAR;
  }

  @Override
  public List<CryptoOperation> getSupportedOperations() {
    return List.of(CryptoOperation.ENCODE);
  }
}

4. Invoker

The CryptoCommandInvoker dynamically maps all factories at startup:

  @PostConstruct
  public void prepareCommandMap() {
    cryptoCommandFactories.forEach(factory -> {
      Map<CryptoOperation, CryptoCommandFactory> innerMap = commandFactoryMap.computeIfAbsent(
          factory.getMethod(), m -> new EnumMap<>(CryptoOperation.class));

      factory.getSupportedOperations().forEach(op -> innerMap.putIfAbsent(op, factory));
    });
  }

  private CryptoCommand getCommand(CryptoCommandInput input) {
    Map<CryptoOperation, CryptoCommandFactory> byMethod = commandFactoryMap.get(input.getMethod());
    if (byMethod == null) {
      throw new IllegalArgumentException("Unsupported method: " + input.getMethod());
    }

    CryptoCommandFactory factory = byMethod.get(input.getOperation());
    if (factory == null) {
      throw new IllegalArgumentException(
          "Unsupported operation: " + input.getOperation() + " for method: " + input.getMethod());
    }

    return factory.create(input);
  }

This removes all switch-case logic and keeps the system open for extension — just add a new factory and command class, and the invoker will pick it up automatically.

---

REST Endpoints

The project exposes three endpoints to showcase different command execution scenarios.

🔹 Single Command

POST /crypto
{
  "operation": "encode",
  "method": "caesar",
  "text": "hello",
  "shift": 3
}

Response:

{
  "operation": "ENCODE",
  "method": "CAESAR",
  "result": "khoor",
  "shift": 3
}

🔹 Batch Commands

POST /crypto/batch
{
  "commands": [
    {"operation":"encode", "method":"caesar", "text":"hello", "shift":3},
    {"operation":"encode", "method":"rot13", "text":"hello"},
    {"operation":"encode", "method":"atbash", "text":"hello"}
  ]
}

Executes multiple commands sequentially and returns an array of results.

🔹 Pipeline Commands

POST /crypto/pipeline
{
  "text": "hello world",
  "commands": [
    {"operation":"encode", "method":"caesar", "shift":3},
    {"operation":"encode", "method":"rot13"},
    {"operation":"encode", "method":"atbash"}
  ]
}

Each command’s output becomes the next command’s input — a great example of command chaining.

---

What Makes This Example Stand Out

• Decoupled Design: The controller, invoker, and commands operate independently.
• Extensibility: Adding a new algorithm only requires a new command + factory.
• Batch & Pipeline Execution: Demonstrates real-world flexibility of the Command pattern.
• Spring Integration: Uses Spring components for discovery and runtime mapping.

---

Takeaways

This project shows how the Command Pattern can elegantly handle dynamic operations — whether they’re single, grouped, or chained.
It’s not just a theoretical example, but a practical demonstration of how design patterns improve scalability and clarity in modern Spring Boot applications.

👉 You can explore the full source code on GitHub:
https://github.com/ercansormaz/command-pattern
